Amana AOC24, Heavy Duty Compact Commercial Microwave, 2400W, Auto-Open Door

The Amana AOC24 is a narrow, 2,400-watt oven for single-serving speed. Its door opens automatically at the end of the cycle and stays open until the next load, so staff close the door and press start in one motion. It is only 13 5/8 inches wide and can be placed back to back on a deep shelf.

Best for:

• Quick-service and coffee chains heating single portions
• Lines that need short cook times, up to 42% faster
• Over-shelf or back-to-back installs where space is tight

Key specifications:

• Model: AOC24
• Power: 2,400 W output, 3,100 W input
• Electrical: 208/240V, 60 Hz, 1 phase, 20 A, NEMA 6-20P plug, 5 ft. cord
• Magnetrons: 2, top and bottom
• Controls: angled bottom touch panel, 10 pads, 100 programmable items, 11 power levels
• Cavity: 11 3/4" W x 8 1/2" D x 5 1/8" H, 0.3 cu. ft.; takes 6"-deep quarter-size pans
• Dimensions: 13 5/8" W x 19 3/16" D x 17 5/8" H
• Weight: 70 lb (shipping weight about 73 lb)

Features:

• Door opens automatically at end of cycle
• Close the door and press start in one motion
• Vertical pop-up door does not block the work area
• "Jigsaw" footprint fits back to back on a 28 1/2" shelf
• Stainless steel interior and exterior
• Door extends out for easy cleaning
• Plug-and-play, ETL listed

Installation notes:

• Plugs into a NEMA 6-20 receptacle on a dedicated 208/240V circuit (20 A)
• Countertop or over-shelf; allow 2" above and 1" on each side
• Optional shelf extender brings an existing shelf to 28 1/2" for back-to-back use

Shipping:

• Free shipping
• Ships by parcel carrier in one carton, about 73 lb
• Residential delivery adds an $85 fee

Warranty:

• 1-year parts and labor warranty from ACP (Amana), with magnetron tube coverage in years 2 and 3 under the ACP limited warranty
