Captive-Aire | SKU:
DTP1/54
Captive-Aire DTP1/54, 1.5 HP 3 phase Continuous duty motor
Regular price
$766.58
Unit price
/
Unavailable
Shipping calculated at checkout.
Captive-Aire DTP1/54, 1.5 HP 3 phase Continuous duty motor is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Captive-Aire DTP1/54, 1.5 HP 3 phase Continuous duty motor
Regular price
$766.58
Unit price
/
Unavailable
Description
Description
rated for 230/460 VAC.
SPECIFICATIONS:
- Material: Metal
- Color: Blue
- HP: 1.5
- Voltage: 230/460
- Phase: 3
- Enclosure type (ODP, TEFC, TENV, TEAO): ODP
- Shaft length: 2.25"
- Center to base: 3.5"
- Time Rating: Continuous
- Insulation Class: F
- Insluation Max Temp: 311 F
- Efficiency: Premium
- Poles: 4
- Nameplate RPM: 1750
- NEMA Frame Size: 145
- Shaft Diameter: Keyway X 7/8"
Specifications
Specifications
| CATEGORY | Motors |
|---|
