Beverage Air PH2-1S-PT Two Section Pass-Thru Heated Holding Cabinet, 4 Solid Doors, 6 Shelf, 208-240V

The Beverage Air PH2-1S-PT is a two-section pass-thru heated holding cabinet, 52" wide, with two full-height solid doors on each side. Food goes in from the kitchen and comes out on the serving side, with 3,000 W of fan-forced heat holding it at 80°F to 180°F. Six shelves and adjustable humidity vents give large operations room and control.

Best for:

• Kitchens feeding a separate serving line or dining room
• Hospitals, schools and correctional kitchens with tray lines
• Banquet halls loading from back of house

Key specifications:

• Model: PH2-1S-PT
• Sections: 2; doors: 4 solid doors (front and rear, pass-thru)
• Shelves: 6 included
• Temperature range: 80°F to 180°F
• Electrical: 208-240V, 60 Hz, single phase, 3,000 W total, 11.3 / 13.0 A; 8' cord with NEMA 6-20P plug
• Overall size: 52.1" W x 38.4" D x 83-3/4" H on 6" legs
• Shipping weight: 509 lb

Features:

• Stainless steel exterior with a corrosion-resistant aluminum interior
• Front-panel thermometer and adjustable thermostat, calibrated from 80°F to 180°F
• Manual humidity vents in the cabinet top let you hold moist or crisp foods
• Two 750 W strip heaters per section with an externally mounted blower for even heat from top to bottom
• Self-closing doors on cam-lift hinges with a heavy-duty cylinder lock and snap-in magnetic gasket
• Pass-thru design: load from the kitchen side and serve from the other
• 6 silver freeze shelves (3 per section)
• 6" adjustable legs; 3" or 6" casters available

Installation notes:

• 208-240V single phase; plan a dedicated 20 A circuit and a NEMA 6-20 receptacle
• Not insulated: keep clear of refrigeration and allow 12" above the top for service
• Door hinging is chosen when ordering; tell us if you need a specific swing
• Leave access on both sides for pass-thru loading

Warranty:

• 7 year parts and labor from Beverage-Air
