CMA 180TC Tall Corner High-Temp Door Dishwasher, 60 Racks/Hr

CMA-180TC Tall Corner High-Temp Machine

For corner layouts that wash a lot of tall ware, the CMA-180TC combines a 27-inch split-door opening with CMA's quick 58-second high-temperature cycle. Racks enter on one side and leave at a right angle.

Where it fits

Suited to hotels, banquet halls and bakeries with an L-shaped dish room and plenty of sheet pans.

Key specifications

• Model: CMA-180TC
• Sanitizing: High Temperature
• Configuration: Single Rack Corner, Tall
• Capacity: up to 60 racks per hour
• Dimensions (W x D x H): 25 1/2" x 25" x 70"
• Weight: 353 lb
• Electrical: 208/240V, Single or Three Phase, 36 A (208V 1-ph, without booster)
• 27" sheet pan door clearance
• 58-second total cycle
• 0.82 gal water per rack
• 7kW wash tank heater; optional 12kW booster
• Certifications: NSF and UL listed; Energy Star
• Warranty: 1 year parts and labor

Installation notes

Built-in 12kW booster available as the 180-TCB. Wire for 208/240V, single or three phase, and provide exhaust ventilation.
