CMA GW-100 Low-Temp Carousel Glasswasher, 1,000 Glasses/Hr, 120V

CMA GW-100 Carousel Glasswasher (120V)

The GW-100 brings carousel glass washing to a standard 120V outlet. It starts itself when a glass is set on the conveyor and stops when the line is clear, and separate detergent, sanitizer and rinse-aid pumps keep glasses clear and streak-free.

Where it fits

Ideal for bars that want carousel speed without running a 208V circuit.

Key specifications

• Model: GW-100
• Sanitizing: Low Temperature Chemical Sanitizing
• Configuration: Carousel Glasswasher
• Capacity: up to 1,000 glasses per hour
• Dimensions (W x D x H): 25 1/4" x 25 1/8" x 40 1/2"
• Weight: 187 lb
• Electrical: 120V, Single Phase, 14.4 A
• 11-3/4" maximum glass clearance
• 1.5kW electric tank heater
• Glass-activated on/off
• Certifications: ETL listed
• Warranty: 1 year parts and labor

Installation notes

Works with iodine or chlorine sanitizer. A 1.5kW tank heater maintains wash temperature; draw is about 14.4A. The cabinet stores three 1-gallon chemical containers.
