Lamber DSP3DPS High-Temp Undercounter Glasswasher w/ Booster & Drain Pump, 30 Racks/Hr

Lamber DSP3DPS Undercounter Glasswasher with Drain Pump

The DSP3DPS takes the small DSP3 footprint and adds a built-in drain pump, so it can pump wastewater up to a drain line instead of relying on gravity. A rotating lower wash arm, a rotating rinse arm and a fixed upper sprayer cover the whole chamber, and a hot booster rinse sanitizes each load.

Where it fits

Built for bars and restaurant service stations where the only drain sits above the machine or across the room. At just over 18 inches wide, it fits where a 24-inch dishwasher will not.

Key specifications

• Model: DSP3DPS
• Sanitizing: High temperature, built-in booster
• Configuration: Undercounter glasswasher with drain pump
• Capacity: up to 30 racks per hour
• Dimensions (W x D x H): 18.1" x 19.9" x 29.2"
• Weight: 95 lb
• Electrical: 208V, single phase, 16 A
• 16" x 16" racks, 11.8" clearance
• 5.2 gal wash tank
• 0.6 gal water per cycle (about 19 gal per hour)
• Built-in detergent pump and rinse-aid dispenser
• Certifications: UL listed
• Warranty: 1 year parts and labor

What's included

• 2 open glass racks (CC00052)
• 1 saucer insert (CC00049)
• 1 cutlery container (CC00045)

Installation notes

Needs a 208V single-phase supply and a 3/4" water inlet, with inlet water at 40-80 psi. Because the pump handles drainage, the outlet can be routed to a drain above floor level.

Shipping

Freight shipping is free on this unit, with liftgate service available at no added cost.
