Southbend HDG-72, 72" Heavy Duty Countertop Gas Griddle, Thermostatic, 180,000 BTU

The Southbend HDG-72 is a 72" heavy-duty Counterline griddle with a 1" thick polished steel plate and 6 thermostatically controlled 30,000 BTU burners, one for every 12" of plate. That is 180,000 BTU per hour behind a 72" x 24" cooking surface, so the plate recovers fast when you load it with cold product.

Best for:

• Breakfast, burger and sandwich lines that run the flat top all day
• Diners, cafeterias and quick-service kitchens
• Countertop setups needing a 72" cooking surface

Key specifications:

• Model: HDG-72
• Cooking surface: 72" x 24", 1" thick polished steel plate
• Overall dimensions: 72" W x 31.75" D x 16.13" H
• Burners: 6 x 30,000 BTU "U" burners, one per 12"
• Total input: 180,000 BTU/hr
• Controls: independent "Insta-on" thermostats with embedded load-sensing bulbs
• Gas: natural gas or propane; 3/4" rear connection with pressure regulator
• Shipping weight: 840 lb

Features:

• 1" thick plate holds heat and spreads it evenly with no cold zones
• Electronic battery spark ignition and flame-failure safety device
• Fully welded griddle plate with protected flue opening
• Reinforced, insulated double-wall sides
• 5" rear and 4" side splash guards
• Large-capacity grease drawer
• 4" stainless steel adjustable legs

What's included:

• Griddle with 1" steel plate
• Grease drawer
• Pressure regulator
• 4" adjustable legs

Installation notes:

• Install under a vented hood
• Installation by a licensed gas professional is required
• Specify natural gas or propane at order
• Season the plate before first use

Warranty:

• 1 year limited parts and labor from Southbend
