Southbend P24-CM, 24" Infrared Gas Cheese Melter, Range Mount, 20,000 BTU

The Southbend P24-CM is a 24-inch infrared cheese melter that mounts on the flue riser of a Southbend range, or on the wall or countertop with the optional kit or legs. 2 infrared burners (20,000 BTU total) reach working heat in about 90 seconds, so you can melt, brown and finish plates back to back without waiting between loads.

Best for:

• Mexican, pub and casual dining lines finishing plates to order
• Melting cheese on nachos, sandwiches, burgers and onion soup
• Kitchens running a Southbend range that want a matching riser-mounted unit

Key specifications:

• Model: P24-CM
• Burners: 2 infrared burners, 10,000 BTU each
• Total input: 20,000 BTU/hr, natural gas or propane
• Cooking cavity: 19" W x 13" D, 247 sq. in., 5 rack positions
• Controls: single valve, high to off
• Dimensions: 24" W x 15.5" D x 21.5" H
• Shipping weight: 90 lb

Features:

• About 90-second preheat with no wait between loads
• 430 stainless steel exterior, #3 polish
• Double-wall reinforced sides and back
• Chrome-plated welded rod broiler rack, 5 positions
• Removable bright-anneal crumb tray
• Air-insulated heat shield under the broiler protects it from range-top heat

Installation notes:

• Range mount on a flue riser is standard; wall mount or countertop with 4" legs is optional
• Gas can be interpiped to a Southbend sectional range base
• Specify natural gas or propane when ordering
• Install under a ventilation hood per local code

Warranty:

• 2 years limited parts and labor from Southbend
